Waiting for Energon Cubes

Energy storage is a key component in our inevitable move away from fossil fuels. If we ever want renewables to take over for base-load demand (having a wind farm keep your fridge running even when the wind isn’t blowing), or drive long distances in plug-in electrics, we’ll need a serious revolution in energy storage.

This is a field I’m very excited about, both in the near term and the long term. It’s an area where there are still big problems to be solved, with lots of opportunities for real ground-up innovation in basic physics, materials science, chemistry and manufacturing.

There’s a need to begin developing our language around energy storage, and to develop a more thorough understanding of the tradeoffs involved. This has been made abundantly clear by the coverage surrounding the battery issues of the Boeing 787 Dreamliner. Most mainstream press has been unable or unwilling to cover the science behind the battery issues, or to accurately explain the decision making that lead to the selection of the type of batteries involved.

When we talk about energy storage, there are two key factors we need to talk about. Energy density and specific energy. Energy density is how much energy you can fit into a given space (megajoules/liter), and specific energy (megajoules/kg) is how much energy you can “fit” in a given mass.

Tesla Roadster.

Tesla Roadster.

Let’s look at a concrete example. The Tesla Roadster relies on a large battery pack, made up of many lithium ion cells. The battery pack weighs 450 kilograms, and has a volume of approximately 610 liters. It stores 53 kilowatt hours of energy (190 MJ). So, it has an energy density of 0.42 MJ/kg and a specific energy of 0.73 MJ/liter.

For comparison, let’s look at the Lotus Elise (I could have said “my Lotus Elise” but I didn’t, because I’m classy), which is fundamentally the same car running on gasoline. It can carry 11 gallons of gasoline in its fuel tank. Gasoline has an energy density of 46 MJ/kg, and a specific energy of 36 MJ/liter (those of you screaming about efficiency, hold on). The 29 kilograms of gasoline in a full tank represent 1334 MJ of energy, approximately 7 times more than the 450 kilogram Tesla battery pack. Frankly, it’s a wonder the Tesla even moves at all!

Lotus Elise.  I think this one is particularly attractive, and probably driven by a very nice person.

Lotus Elise. I think this one is particularly attractive, and probably driven by a very nice person.

Now, it’s important to add one more layer of complexity here. Internal combustion engines aren’t particularly efficient at actually moving your car. They’re very good at turning gasoline into heat. The very best gasoline engines achieve approximately 30% efficiency at their peak, so of that 1334 MJ in the Lotus’ tank, perhaps only 400 MJ are actually used to move the car. The rest is used to cook the groceries that you probably shouldn’t have put in the trunk. The electric drive train in the Tesla on the other hand is closer to 85% efficient.

That’s a quick example of why understanding some of the engineering, science, and math behind energy storage is important – without means for comparison, it can be difficult to grasp the tradeoffs that have been made, and why products end up being designed the way that they are.

I’ll dig deeper into the specific types of battery technologies on the market and the horizon in a future post. At the moment, they’re all within approximately the same ballpark for density and specific energy, and simply offer different tradeoffs in terms of charge times, safety, and longevity.

Batteries are not the only way to store energy though, and aren’t nearly as sexy as some of the alternatives.

Fuel cells have fallen out of vogue a bit over the last few years. While Honda forges on, most of the excitement seems to have been supplanted, for now, with acceptance of the fact that the lack of a large-scale hydrogen distribution network dooms them to a chicken-or-the-egg fate for the foreseeable future. Fuel cells operate by combining stored hydrogen with oxygen from the air, to release energy. Because hydrogen can be made by electrolyzing water, fuel cells are a feasible way of storing energy generated by renewable sources.

Due to the increased efficiency of an electric drivetrain and the high energy density (though lower specific energy) of hydrogen, a fuel cell drivetrain can rival gasoline for overall system efficiency. Unfortunately, they achieve all of this using a variety of exotic materials, resulting in costs that are completely unrealistic (think hundreds of thousands of dollars per car) and look likely to remain there for the foreseeable future. That said, just today saw word of a fuel cell technology-sharing deal between BMW and Toyota – perhaps there’s still some life in this space.

There’s another type of energy storage, which excites me most of all – these are the “use it or lose it” short term energy storage technologies, which are designed primarily to replace batteries in hybrid drivetrains, or to smooth short term power interruptions in fixed installations.

I’d like to explore these further in depth in the future, but for now, a quick survey is appropriate. The technology I’m most interested in is kinetic energy storage in the form of flywheels. At it’s most basic, you take a wheel, get it spinning, and then couple it to a generator to convert the motion back into electricity.

This is an old technology. Traditionally, you used very heavy wheels, spinning relatively slowly. This type of system is sometimes used in place of batteries for short term power in data centers. In the last few years, flywheels have gotten interesting for smaller-scale applications as well, thanks to modern materials sciences. A small amount of mass spinning very fast can store the same amount of energy as a large amount of mass spinning very slowly. Modern materials and manufacturing mean it’s realistic to build a hermetically sealed flywheel which can spin at hundreds of thousands of RPM. Ricardo has done just that, as has Torotrak.

These systems have the advantage of being relatively lightweight, simple and low-cost. While they don’t store a large amount of energy, they’re ideal for regenerative braking and increasing the overall efficiency of an ICE drivetrain.

Another category of energy storage is thermal storage. These are what they sound like – means to store heat (from solar most often) for extended periods of time. This is another old technology, with some interesting new twists. Remember that gasoline engines turn lots of their energy into heat. Some manufacturers are experimenting with systems which can convert some of that heat into energy, using good old fashioned steam.

A final type of storage which doesn’t fit nicely into any category is compressed air. This week, Peugeot-Citroen (PSA) unveiled their compressed air hybrid drivetrain. This system uses compressed air pressurized by an onboard pump, driven through regenerative braking and other “waste” energy capture. While more complex than a flywheel, total energy storage is much greater as well, and PSA is talking of 30% reductions in emissions thanks to this technology. Tata has also experimented with cars using the MDI compressed air drivetrain, which is designed to be “fueld” by an offboard compressor.

As I noted at the beginning, part of what makes me excited about this space is that it’s not a solved problem. There are loads of companies all around the world creating innovative solutions. Most of them will probably fade away, but some have a reasonable chance of replacing or supplementing the “status quo” energy storage options we have today. Interestingly as well, no one country is dominating the research in this space. The UK, in keeping with tradition, has a large number of very small companies working on projects (their “cottage industries” are often actually housed in cottages!), while the US does this sort of development primarily via research institutions, and other countries rely on government-run labs.

Until all are one, bah weep grana weep ninny bon.

Yet Another Blog Reboot

I’ve lost track of how many blogs I’ve had over the last 15 years.  While most of them have been personal or travel-oriented in nature, I’ve maintained Discrete Cosine – on and off – since January of 2006.

Originally, Discrete Cosine was intended as a video-industry oriented site – news, reviews and tips on things I was doing while working in the TV Studios at the University of Minnesota.  Over time, it followed my migration into academic-technology oriented work, and then became fully dormant when I left the University in August of 2011.

I’ve now migrated the old Discrete Cosine content to the WordPress platform, and that’s where you find yourself now.  Rather than start fresh, I’m considering this a bit of a reboot – I like the Discrete Cosine name too much to leave it behind.

For now, this site will just be a place for me to post thoughts about technology (and related stuff) which are too long to fit in a tweet.

I’ll continue to post more personal content on the major social networks, and my travel blogging will continue to live at travel.discretecosine.com.

We’ll see how long this lasts, but for now, it’s a start.  Please bear with me as I get things a bit more organized.

An introduction to reverse engineering

(This blog is still in hibernation, but I needed somewhere to post this)
Reverse engineering is one of those wonderful topics, covering everything from simple “guess how this program works” problem solving, to poking at silicon with scanning electron microscopes. I’m always hugely fascinated by articles that walk through the steps involved in these types of activities, so I thought I’d contribute one back to the world.
In this case, I’m going to be looking at the export bundle format created by the Tandberg Content Server, a device for recording video conferences. The bundle is intended for moving recordings between Tandberg devices, but it’s also the easiest way to get all of the related assets for a recorded conference. Unfortunately, there’s no parser available to take the bundle files (.tcb) and output the component pieces. Well, that just won’t do.
For this type of reverse engineering, I basically want to learn enough about the TCB format to be able to parse out the individual files within it. The only tools I’ll need in this process are a hex editor, a notepad, and a way to convert between hex and decimal (the OS X calculator will do fine if you’re not the type to do it in your head).
Step 1: Basic Research
After Googling around to see if this was a solved issue, I decided to dive into the format. I brought a sample bundle into my trusty hex editor (in this case Hex Fiend).
A few things are immediately obvious. First, we see the first four bytes are the letters TCSB. Another quick visit to Google confirms this header type isn’t found elsewhere, and there’s essentially no discussion of it. Going a few bytes further, we see “contents.xml.” And a few bytes after that, we see what looks like plaintext XML. This is a pretty good clue that the TCB file consists of a . Let’s scan a bit further and see if we can confirm that.
In this segment, we see the end of the XML, and something that could be another filename – “dbtransfer” – followed by what looks like gibberish. That doesn’t help too much. Let’s keep looking.
Great – a .jpg! Looking a bit further, we see the letters “JFIF,” which is recognizable as part of a JPEG header. If you weren’t already familiar with that, a quick google for “jpg hex header” would clear up any confusion. So, we’ve got the basics of the file format down, but we’ll need a little bit more information if we’re going to write a parser.
Step 2: Finding the pattern
We can make an educated guess that a file like this has to provide a few hints to a decoder. We would either expect a table of contents, describing where in the bundle each individual file was located, some sort of stop bit marking the boundary between files, byte offsets describing the locations of files, or a listing of file lengths.
There isn’t any sign of a table of contents. Let’s start looking for a stop bit, as that would make writing our parser really easy. Want I’m going to do is pull out all of the data between two prospective files, and I want two sets to compare.
I’ve placed asterisks to flag the bytes corresponding to the filenames, since those are known.
1E D1 70 4C 25 06 36 4D 42 E9 65 6A 9F 5D 88 38 0A 00 64 62 74 72 61 6E 73 66 65 72 42 06 ED 48 0B 50 0A C4 14 D6 63 42 F2 BF E3 9D 20 29 00 00 00 00 00 00 DE E5 FD
01 0C 00 63 6F 6E 74 65 6E 74 73 2E 78 6D 6C 9E 0E FE D3 C9 3A 3A 85 F4 E4 22 FE D0 21 DC D7 53 03 00 00 00 00 00 00
The first line corresponds to the “dbtransfer” entry, the second to the “contents.xml” entry. Let’s trim the first entry to match the second.
38 0A 00 64 62 74 72 61 6E 73 66 65 72 42 06 ED 48 0B 50 0A C4 14 D6 63 42 F2 BF E3 9D 20 29 00 00 00 00 00 00
01 0C 00 63 6F 6E 74 65 6E 74 73 2E 78 6D 6C 9E 0E FE D3 C9 3A 3A 85 F4 E4 22 FE D0 21 DC D7 53 03 00 00 00 00 00 00

It looks like we’ve got three bytes before the filename, followed by 18 bytes, followed by six bytes of zero. Unfortunately, there’s no obvious pattern of bits which would correspond to a “break” between segments. However, looking at those first three bytes, we see a 0x0A, and a 0x0C, two small values in the same place. 10 and 12. Interesting – the 12 entry corresponds with “contents.xml” and the 10 entry corresponds with “dbtransfer”. Could that byte describe the length of the filename? Let’s look at our much longer JPG entry to be sure.
70 4A 00 77 77 77 5C 73 6C 69 64 65 73 5C 64 37 30 64 35 34 63 66 2D 32 39 35 62 2D 34 31 34 63 2D 61 38 64 66 2D 32 66 37 32 64 66 33 30 31 31 35 65 5C 74 68 75 6D 62 6E 61 69 6C 73 5C 74 68 75 6D 62 6E 61 69 6C 30 30 2E 6A 70 67
0x4A – 74, corresponding to a 74 character filename. Looks like we’re in business.
At this point, it’s worth an aside to talk about endianness. I happen to know that the Tandberg Content Server runs Windows on Intel, so I went into this with the assumption that the format was little-endian. However, if you’re not sure, it’s always worth looking at words backwards and forwards, just in case.
So we know how to find our filename. Now how do we find our file data? Let’s go back to our JPEG. We know that JPEGs start with 0xFFD8FFE0, and a quick trip to Google also tells us that they end with 0xFFD9. We can use that to pull a sample jpeg out of our TCB, save it to disk, and confirm that we’re on the right track.
This is one of those great steps in reverse engineering – concrete proof that you’re on the right track. Everything seems to go quicker from this point on.
So, we know we’ve got a JPEG file in a continuous 2177 byte segment. We know that the format used byte lengths to describe filenames – maybe it also uses byte lengths to describe file lengths. Let’s look for 2177, or 0x8108, near our JPEG.
Well, that’s a good sign. But, it could be coincidental, so at this point we’d want to check a few other files to be sure. In fact, looking further in some file, we find some larger .mp4 files which don’t quite match our guess. It turns out that file length is a 32bit value, not a 16bit value – with our two jpegs, the larger bytes just happened to be zeros.
Step 3: Writing a parser
“Bbbbbut…”, I hear you say! “You have all these chunks of data you don’t understand!”
True enough, but all I care about is getting the files out, with the proper names. I don’t care about creation dates, file permissions, or any of the other crud that this file format likely contains.
Let’s look at the first two files in this bundle. A little bit of byte counting shows us the pattern that we can follow. We’ll treat the first file as a special case. After that, we seek 16 bytes from the end of file data to find the filename length (2 bytes), then we’re at the filename, then we seek 16 bytes to find the file length (4 bytes) and seek another 4 bytes to find the start of the file data. Rinse, repeat.
I wrote a quick parser in PHP, since the eventual use for this information is part of a larger PHP-based application, but any language with basic raw file handling would work just as well.
tcsParser.txt
This was about the simplest possible type of reverse engineering – we had known data in an unknown format, without any compression or encryption. It only gets harder from here…

Presentation on the HTML5 video tag

A few weeks back, I was given the opportunity to present at MinneWebcon. My talk, “<video> will be your friend” focused on the legal issues and implementation possibilities surrounding the HTML5 video tag.

I’ve put my slides online, if you want to take a look. I’ve also recorded the first half the of the lecture as part of a test of our Mocha class capture application. I’ll be recording the second half Real Soon Now.

Podcast Producer 2 tip – running xgrid jobs as logged in user

So I’ve been playing with an interesting “feature” in PCP2 – the “chapterize” command generates different results when it can talk to the window server versus when it can’t. In my case, it generates much better results in the case of the former.

“But,” you say, “my PCP2 xgrid jobs can’t talk to the window server!”

Very true. However, you can change the user that PCP2 uses to submit Xgrid jobs, and Xgrid will run the job with that user’s permissions if everyone is single signon’d to the same kerberos domain.

So, now we’ve got PCP2 jobs running as a real user. Next, log into the GUI as that user.

Now, when PCP2 workflows run, they’ll be able to talk to the window server, and at least in the case of “chapterize,” use what appears to be the “Good” code path. Faster, more accurate, more delightful.

Pcpserveradmin

Quicktime Eats Cookies

It appears that when embedding Quicktime in a webpage, being viewed by Safari 4 in Snow Leopard, Quicktime no longer passes cookies to the server. So, if you’re having the Quicktime plugin load a file that uses cookie data to verify permissions, you’ll need to move to a query string model.
This only happens when Safari is running in 64bit mode, so I imagine it has to do with the “plugins running as separate entities” crash protection that Snow Leopard adds.
This does not appear to impact the Flash plugin.

Podcast Producer 2: Where I’m at

If all of this scheduled publishing stuff has worked, you’ll find a handful of posts about Podcast Producer 2 below.
I just took all of the notes I’ve collected while working on a PCP2 project over the last month or so, and wrote them up. It’s entirely possible that there are all sorts of things I’m missing, or misunderstanding. Now that the NDA is expired, hopefully some more folks will go public with their own discoveries.
So, if you’re coming across these posts and you know things I don’t about this strange world of ruby and media, please let me know in the commments!

Podcast Producer 2: Custom Chapterization Settings

Podcast Producer 2 has a really neat tool to automatically create a chapter marker each time a slide is changed in a screen recording of a powerpoint or other presentation. It does that by detecting the change between images, with some boundaries.
The default settings are a bit too aggressive in my opinion – more than a few times I’ve ended up with hundreds of chapter markers in a presentation that only consisted of a few slides. Also, if you’re using an Epiphan screen recorder instead of the podcast producer screencapture tool, you’re likely to have additional noise in the feed which could confused it.
Luckily, you can override the default settings. Chapterization takes advantage of a tool called ‘chapterize’ that lives in /usr/libexec/podcastproducer/. What I’d suggest doing is creating a few sample recordings in your typical environment and then playing with chapterize switches to find the right combination.
Chapterize adds chapters to the movie itself, rather than creating a copy, so you’ll want to backup your file before running it. You can run the command directly to see all of the switches.
I’m working with 1024×768 screen recordings, and I found that bumping up the –reduce ratio number to 8 or 12 substantially reduces the false positives.
Once you’ve found the right combination of settings, you’ll want to modify /usr/lib/podcastproducer/actions/pip.rb, chapterize.rb and qtimport.rb – just search the file for chapterize, it should be pretty self explanatory.

Podcast Producer 2: Extract Chaptered XML

The chapterize command has the option of outputting an XML in addition to (but not instead of) modifying the source quicktime. You can take advantage of this in cases where you’d like the raw chapter data, perhaps for creating your own thumbnail gallery.
Just add the -xml flag and specify a file. You can modify the:
/usr/lib/podcastproducer/actions/pip.rb
file to do this automatically, and then have your workflow take care of moving the files around. No need to specify a path, it’ll end up in the Content folder with the rest of your media. So, here’s what my pip.rb has ended up looking like, from line 125 to 139:
args = [ “/usr/libexec/podcastproducer/chapterize”,
“–input”,
chapterized_primary_input_path,
“–xml”,
“chapterize.xml”,
“–threshold”,
“10.0”,
“–tolerance”,
“3”,
“–reduce”,
“12”,
“–window”,
“0.3”
]
do_system(*args)
